Wireless charging system 600W specication
For 12V・24V・48V battery
84
154
170
26
1500
100
4ｘ
7
ﾌｪﾗｲﾄｺｱ
RFC-H13
45
5
Standard Specication Passive Head
3P connector
for power supply
5P connector
for communication
Ferrite clamp
Long Distance
Specication Passive head
135 150
235
250
4 x
7
( 1500 )
7
40
RCS600-CH-L
RCS600-CH-L
Made in japan
Serial No. xxxxxxx
135 150
235
250
4 x 7
( 1500 )
7
40
RCS600-CH-L
RCS600-CH-L
Made in japan
Serial No. xxxxxxx
3P connector
for power supply
5P connector
for communication
Standard Specication Passive Head Long Distance Specication Active Head
Type code RCS600-CH(1.5m),RCS600-CH-
01(1.0m),RCS600-CH-005(0.5m)
RCS600-CH-L(1.5m), RCS600-CH-L-01(1.0m)
RCS600-CH-L-005(0.5m)
Applicable unit RCS600(B)-CA24 or RCS600(B)-CA12 or RCS600(B)-CA48
Rated gap Distance 0 ～ 20mm
20 ～ 40mm * Be sure to follow the specied
distance.Using outside the specications may
damage the equipment.
Center o󱐯set ± 10 mm in the X axis direction and ± 15 mm
in the Y axis direction (For details, see P. 13)
± 10mm in X axis direction. ± 20mm
in Y axis direction. However, the total
displacement of the XY axes can be up to
20mm. (See page 13 for details)
Operating temperature 0...50℃
Storage temperature -10...50℃
Operating humidity 35 ... 90% RH or less However, no condensation
Isolation ≧ 50M Ohm
Dielectric strength 2000 VAC / 1min
Shock rating 10 G, in the X, Y, and Z directions 11ms
Vibration rating 19.6 m / sec
2
(10 to 55 Hz), 20 times in X and Y directions
Protection class IP65 (Indoor installation type) IP6X (Indoor installation type)
Weight(including cable connector part) 2.0kg(Cable length1.5m)/1.8kg(Cable length0.5m) 3.1kg(Cable length1.5m)/2.9kg(Cable length0.5m)
Connection Supply Connected to the Charging unit at the
(female) 3-pin round
Connected to the Charging unit at the (fe-
male) 3-pin round
communication Connected to the Charging unit at the
(female) 5-pin round
Connected to the Charging unit at the (fe-
male) 5-pin round
Material Case PPS, aluminum PPS, aluminum
Output cable φ 8.6 2.5mm
2
ｘ3 PUR φ 8.6 2.5mm
2
ｘ3 PUR
Communication cable
φ 5.6 0.3mm
2
ｘ4 PUR φ 5.6 0.3mm
2
ｘ4 PUR
Mounting part For enclosure xing φ 7×4 places
Accessories Central positioning label, ferrite clamp
RFC-H13(white) 1PC.
Central positioning label, ferrite clamp
E04SR401938 for charging cable (gray) 1PC.
Max. cable length when us-
ing optional cable
5.0m 5.0m *
Extending the cable of a long-distance head
may cause premature switching of CC ⇒ CV.
Remarks See page 26-27 for cable variations.
