Wireless charging system 600W specication
For 12V・24V・48V battery
Name Function Display Output
Power Display main power supply Lit green Present
Ready
Displayed in the stopped charging state
(charging standby state)
Lit blue Present
Charge
Displaying during constant current
or voltage charge operation
Lit orange Present
End Display the end of charging Lit green Present
Error Indicates abnormality Lit red Present
Error code
Display abnormal contents by com
-
bination E1 ～ E3.
Lit red Present
For details on how to identify and deal with abnormalities, please refer
to “Identifying and Troubleshooting Abnormalities” on page 28.
〇 Connector specication 〇
If necessary, the followings
are recommended.
Connector: D-sub 25 pin (male)
Soldering type：HDBB-25P (05) Hirose Electric
Case made by HDB-CTH Hirose Electric
Terminal block type：SUBCON 25M-SH made by Phoenix Contact
Protective cap：DB-25S-DC1 Hirose Electric
Mounting screw: M2.6 (mm screw)
6.LED/IO connector for each units
Power supply unit（RCS600-AC）
I/O connector
LED output display
Output signal circuit diagram
Fitting surface of connector (cable wiring side)
13 12 11 10 9 8 7 6 5 4 3 2 1
25 24 23 22 21 20 19 18 17 16 15 14
L
O
A
D
18 17 16 8 7 6 5 4
DC 24V
power
supply
－
＋
20
* Both NPN and PNP can be wired.The gure is an example of NPN wiring.
L
O
A
D
L
O
A
D
L
O
A
D
L
O
A
D
L
O
A
D
L
O
A
D
L
O
A
D
Pin.
Pin.
Charge
End
Error
電源ユニットのみ
Power
電源ユニット側
Input
Input signal schematic
Output signal schematic
external
external
internal
internal
dry contact
ca.2mA
Pin.14
Pin.1
2k Ω
2k Ω
5V
Output
(Only for Power supply unit)
Power
less than
50mA
4
5
39V
39V
39V
6
7
8
16
17
18
39V
39V
39V
39V
39V
39V
Ready
Charge
End
Error
E1
E2
E3
less than30V
20
無電圧接点
Pin.
Pin.
Charge
End
Error
電源ユニットのみ
Power
External output
signal
Ready Power
Charge
Error
E1 E2 E3
End
■ Periodic inspection
Inspection point Inspection details Inspection method
All units (once/year)
Check for looseness and missing screws, bolts, nuts, etc.
Whether dust has accumulated on each device
Check visually and retighten.
Battery inspection (at least 1-2
times/year)
Whether the battery has deteriorated
Check according to the battery manufacturer's
instruction manual or specications.
Check the cooling status of the
power supply unit
(1-2 times or more/year)
Whether the slits of the inlet or exhaust port are
clogged with dust, etc..
Whether foreign matter is attached
Whether the cooling fan is working without abnormal noise
Please check visually, sound, and airow,
and if necessary, clean or replace (consult
with our person in charge).
Check if the charging unit output
setting is the specied value
(twice/year)
Check the charging voltage/current settings
Measure with a voltmeter and ammeter at
the charging unit output terminals.
Check the usage conditions
(at least 1-2 times/year)
Whether the transmission distance between heads uctuates
greatly (is it within the transmission distance range?)
Check whether the cooling function has deteriorated due to
accumulation of dust, etc. around the equipment.
Please check visually, with a distance meter, etc.
If there is a problem, please adjust and clean
