Push the adaptor further in until the O-ring is fully inside the emission port. At this
point the adaptor should be positioned firmly into its position.
Using the Point-and-Shoot Adaptor
The Point-and-shoot adaptor can be used for powder, solid or liquid sample
measurements through a thin and transparent container. With the Point-and-shoot
adaptor in place, hold the NanoRam unit so that the adaptor is against the sample
container surface.
Note: B&W Tek does not recommend that the adaptor touch powder samples directly,
as they may contaminate the lens on the sampling adaptor. The use of a protective
transparent plastic film is recommended.
Precaution: to avoid accidental exposure to the laser beam
do not look directly into laser emission aperture.
