Using the Liquid Vial Holder Adaptor
The liquid vial holder can be used for liquid, gel, or powder samples. The liquid vial
holder holds a 15 mm (diameter) x 45mm (height) vial.
Using the Bottle Adaptor
The bottle adaptor can be used for the measurement of samples through transparent
containers of less than 5 mm in thickness, such as liquid samples inside bottles, or
containers. The bottle or container can be placed directly against this adaptor. The
measurement beam will then be ideally focused into the sample over 5 mm away
from the surface of the adapter.
The NanoRam Mini unit standard package comes with three types of sampling
accessories which will facilitate easy and fast sampling. Depending on the type and form
of the materials to be measured, the appropriate sampling accessory can be selected.
The sample can be placed directly against the adaptor.
Point-and-shoot adaptor
Bottle adaptor
Liquid vial holder adaptor
