Banner D10 Expert - Advanced Setup and Lockout; Advanced Setup Options; Push Button Lockout Feature

P/N 64154 rev. F 11
D10 Expert
™
Dual Discrete Outputs
Banner Engineering Corp. • Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Advanced Setup
•Advancedadjustmentstopreviouslyconguredsensordisplayandoperatingparameters.
•Quad-clickStatic(-)orquad-pulseremotelinebeforeexiting“PowerandSpeed”settingstoenterthismode.
•ClickDynamic(+)ordouble-pulseremotelinetoselectanoption.
•ClickStaticorsingle-pulseremotelinetoadvance.
•Changesareupdatedinstantly.
Push Button Lockout
•Preventsunwantedadjustmentsortamperingofthepushbuttons.
•PushbuttonscanbeenabledordisabledonlyfromtheremotelineandonlyduringnormalRUNmode.
Push Button
Remote
0.04 sec. ≤ T ≤ 0.8 sec.
Result
Enable or Disable
Push Buttons
•Notavailablewith
push-button programming.
•FromRUNmode,
quad-pulse the
remote line to toggle
between selections.
Push Buttons Disabled:
•Displayflashes“loc”
•Padlockiconappears
•SensorremainsinRUNmode
Push Buttons Enabled:
•Displayflashes“uloc”
•Padlockicondisappears
•SensorremainsinRUNmode
TT
T
TTTT
TTT
dynamic
static
dynamic
static
Push Button
Remote
0.04 sec. ≤ T ≤ 0.8 sec.
Result
Enter
SETUP
Mode
•From“Power
and Speed”
mode, quad-click
Static (-) button.
•From“Power
and Speed” mode,
quad-click the
remote line.
•IndicatorArrowIcons
1 and 2 remain red
•Displayshows
“TrackingEnabled”option.
Track Enable
•ClickDynamic(+)
to toggle
between selections.
•Double-pulsethe
remote line to toggle
between selections.
Sets output 2 identical to output 1
Tracking disabled:
•Displayshows“tr n”
Tracking enabled:
•Displayshows“tr y”
•ClickStatic(-)to
save selection and
advance to
 “FactoryDefault.”
•Single-pulsetheremote
line to save selection
and advance to
 “FactoryDefault.”
Factory Default Settings
•ClickDynamic(+)
to toggle
between selections.
•Double-pulsethe
remote line to
toggle between
selections.
Returns to factory default factory settings
Factory Default Settings
Not Selected:
•Displayshows“fd n”
Factory Default Settings
Selected:
•Displayshows“fd y”
•ClickStatic(-)to
advance to
 “DisplayOrientation.”
•Single-pulsethe
remote line to
advance to
 “DisplayOrientation.”
Display Orientation
•ClickDynamic(+)
to toggle between
selections.
•Double-pulsethe
remote line to toggle
between selections.
Inverts display to read “upside-down”
Normal:
•Forexample:1234
Inverted:
•Forexample:
NOTE: Icons do not invert.
•ClickStatic(-)to
return to
RUN mode.
•Single-pulsethe
remote line to
return to RUN mode.
