Banner D10 Expert - Page 13

P/N 64154 rev. F 13
D10 Expert
™
Dual Discrete Outputs
Banner Engineering Corp. • Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Dimensions
10.0 mm
(0.39")
35.1 mm
(1.38")
10.0 mm
(0.39")
15.2 mm
(0.60")
2x C'sink
ø8.0 mm (0.31")
3.2 mm (0.13") deep
ø4.4 mm (0.18") thru
2x 3.5 mm
(0.14")
5.0 mm
(0.20")
8.6 mm
(0.34")
25.4 mm
(1.00")
16.0 mm
(0.63")
2 x ø3.3 mm (0.13")
2x ø3.2 mm (0.13")
2.5 mm (0.10")
5.0 mm (0.20")
M3 Hardware included:
Lock Washer (2)
Flat Washer (2)
Screws (2)
Hex Nuts (2)
Included Bracket Dimensions
61.3 mm
(2.42")
68.1 mm
(2.68")
Plastic Fiber
Emitter Port
Plastic Fiber
Receiver Port
10.5 ± 0.2 mm (typ.)
(0.41")
Mounting Bracket
(included)
Slides Up to
Release Fibers
35.9 mm
(1.41")
7.6 mm
0.30"
9.8 mm
(0.39")
