Opposed Mode Diffuse Mode
0.4" Diameter Fibers
PIT46U
HS/STD
LR
XLR
1
10
100
1000
10000
100000
1 10 100 1000
DISTANCE (mm)
EXCESS GAIN
PBT46U
HS/STD
LR
XLR
1
10
100
1000
10000
0.1 1 10 100 1000
DISTANCE (mm)
EXCESS GAIN
0.6" Diameter Fibers
PIT66U
HS/STD
LR
XLR
1
10
100
1000
10000
100000
1 10 100 1000
DISTANCE (mm)
EXCESS GAIN
PBT66U
1
10
100
1000
10000
0.1 1 10 100 1000
DISTANCE (mm)
EXCESS GAIN
HS/STD
LR
XLR
DF-G1 - Expert Dual Display Fiber Amplifier Manual
22 www.bannerengineering.com - tel: 763-544-3164 P/N 161999 Rev. A
