1. Antenna, see the section called “Assembly” for details.
2. Power / Volume knob, usage discussed in the section called “Power and volume”.
3. Two-line LCD
4. Call key
5. PTT key, usage discussed in the section called “Making a call”.
6. Monitor key
7. Keypad
8. Speaker and microphone
9. Accessory jack
10. VFO/MR mode key
11. Status LED
12. A / B select key
13. Battery pack; see the section called “Charging and battery maintenance” for details.
14. Battery contacts
15. Battery release latch
16. Lanyard loop
17. LED flashlight - See the section called “Side key 2 - MONI (Monitor and Flashlight)” for
more information.
