BF-F8HP!
!
!
!
The main display
Figure 2.2. BaoFeng BF-F8HP, display
The transceiver is fitted with a seven character by two line dot matrix alphanumeric LCD, with auxiliary
icons for miscellaneous features.
Table 2.1. LCD icon summary
Icon
Description
Icon
Description
188
Memory channel
R
Reverse function enabled
25, 75
Least significant modifiers.
N
Narrowband enabled
CT
CTCSS enabled
Battery level indicator
DCS
DCS enabled
Keypad lock enabled
+, -
Frequency shift direction if enabled in VFO
H, M, L
Transmit power level indicator
According to Power (High, Mid, Low)
+-
Frequency shift direction if enabled in MR
S
Dual watch enabled
Indicates active band or channel
VOX
VOX enabled
Squelch Open/ Close Indicator
