Appendix C. - Technical specifications
General
General specifications
Specification Value
Frequency Range (MHz) 65-108 (Rx only)
144-148 (Rx/Tx)
420-450 (Rx/Tx)
Memory channels 128
Frequency stability 2.5ppm
Frequency step (kHz) 2.5K/5.0K/6.25K/10.0K/12.5K/20.0K/25.0K/50.0K
Antenna impedance 50 Ohm
Operating temperature -20°C to +60°C
Supply voltage 7.4
Consumption ≤ 75mA (standby)
380mA (reception)
≤ 1.4A (transmission)
Mode of operation Simplex or semi-duplex
Duty cycle 03 / 03 / 54 min. (Rx / Tx / Standby)
Dimensions (mm) 58 x 110 x 32
Weight (g) 214
