SPECIFICATION (CPD20 CPD25)
General
Model
CPD20
CPD25
Power type
Battery
蓄电池
Rated capacity
kg
2000
2500
Load center
mm
500
Dimension
Lift height
H
mm
3000
Free lift height
H4
mm
140
Fork size
L×W×T
mm
1070×120×40
1070×120×45
Fork outside spread (Min./Max)
B4
mm
240/1040
Mast tilt angle (forward/backward)
α/β
°
6/12
Front overhang
X
mm
479
484
Overall
dimension
Length to fork face
L1
mm
2349
2381
Overall width
B1
mm
1152
Mast lowered height
H1
mm
2060
Mast extended height
H3
mm
4040
Overhead guard height
H2
mm
2159
Min. turning radius
R
mm
2050
2100
Min. right angle stacking aisle width
RAXA
mm
3715
3755
Performance
No load/
full load
Travel speed
km/h
12.5/11
12.5/10.5
Lifting speed
mm/sec
400/260
390/250
Max. grade ability
%
10
15
Service weight
kg
4160
4360
Max. pull force(full load)
KN
8
Chassis
Tyre
Front
mm
7.00-12-12PR
Rear
mm
18×7-8-14PR
Tread
Front
B2
mm
960
Rear
B3
mm
950
Wheelbase
Y
Y
1500
1250
Ground
clearance
(No load / full
load)
Mast
M
mm
120/100
Frame
F
mm
120/100
Power & Control
Battery
Voltage
V
48
48
Capacity
Ah
*630/700
Motor
Drive motor
KW/rpm
7.0/1400
Hydraulic motor
KW/rpm
8.6/1600
Controller
GE separate excitation controller
