23
Default configuration parameter list:
Table 1 Table 2
Parameter European USA
P1 1 9
P2 0°C 0°F
P3 400°V 999°F
P4 H H
P5 rEL rEL
P6 Air Air
P7 1 1
P8 HA HA
P9 OFF OFF
P10 0 0
P11 HA HA
P12 OFF OFF
P13 0 0
P14 0 0
P15 0 0
P16 OFF OFF
P17 10 Amps 10 Amps
P18 0 0
P19 rEV rEV
P21 diR diR
P22 diR diR
P23 OFF OFF
P24 10%/s 10%/s
P25 ON ON
P26 2 2
P27 30% 30%
P28 1.0% 1.0%
P29 1.5% 1.5%
P30 00.3 00.3
P31 10 10
e)Use the s key to select table 1 (European) or table 2
(American) default parameters; the display will show:
g) Press the FUNC key; the display will show:
This indicates that the loading procedure has been
initiated. After about 3 seconds the loading procedure
is complete and the instrument reverts to the “COnF”
display. The following table is a list of the default
configuration parameters loaded during the procedure:
