4
CAUTION: USE WIRE SUITABLE
FOR 75 °C MINIMUM
Contents
1/8 DIN, THREE DIGIT DISPLAY TEMPERATURE
CONTROLLER .................................................. 2
MOUNTING REQUIREMENTS ................................... 5
DIMENSIONS AND PANEL CUTOUT ......................... 6
WIRING GUIDELINES ................................................ 7
CONFIGURATION PROCEDURE ............................. 13
Preliminary Hardware Settings ........................ 13
Configuration Key Functions ........................... 14
Configuration Procedure ................................. 14
Advanced Configuration Procedure ................ 16
OPERATING MODE ................................................. 17
Operating Key Functions ................................. 17
Autotuning (Smart AT) Function ....................... 18
Manual Reset of the Alarms ............................ 18
Enable/Disable the Control Output.................. 18
Lamp Test ........................................................ 18
OUT 1 Heater Breakdown Alarm ..................... 18
Operating Parameters ..................................... 19
Error Messages ............................................... 19
Error messages ............................................... 20
Default Parameters .......................................... 20
SPECIFICATIONS .................................................... 23
General ............................................................ 23
Control Actions................................................ 23
Inputs .............................................................. 23
Current Transformer Input for OUT 1 Heater
Breakdown Detection (Optional) ............. 24
CALIBRATION PROCEDURE ................................... 26
Calibration Parameters .................................... 26
Procedure ........................................................ 26
Entering Calibration Values .............................. 27
MAINTENANCE ....................................................... 30
