SPECIFICATIONS
General
Case: Dark grey polycarbonate. Self-extinguishing
degree V-0 according to UL94.
Front Protection: Designed and tested for IP65 and
NEMA 4X.
Installation: Panel mounting by means of brackets.
Rear Terminal Block: 21 screw terminals with safety rear
cover.
Dimensions: 48 x 96mm (1.890 x 3.870 in.) according to
DIN 43700; 89mm (3.504 in.) depth.
Cutout: 45 mm -0 mm, +0.6 mm x 92 mm, -0, +0.8 mm
(1.772 in -0 in, +0.024 x 3.662 in, -0 +0.031 in)
Weight: 600 grams max. (1.6 lbs.).
Power Supply (Switching Mode):
100 to 240 Vac. 50/60 Hz (+10 to -15% of the
nominal value) or 24 Vac/Vdc (±10% of the
nominal value).
Power Consumption: 6 VA.
Insulation Resistance: Greater than 100 MΩ according
to IEC 1010-1.
Isolation Voltage: 1500 Vrms according to IEC 1010-1.
D/A Conversion: Dual slope integration.
Electromagnetic Compatibility and Safety Requirements:
This instrument is marked CE. Therefore, it is
conforming to council directives 89/336/EEC
(reference harmonized standard EN50081-2
and EN50082-2) and to council directivew 73/
23/EEC and 93/68/EEC (reference harmonized
standard EN61010-1).
Installation Category: II
Temperature Drift: <200 ppm/°C (RJ excluded) <400
ppm/°C for RTD input with -19.9/99.9°C range.
Sampling Time: 500 ms.
Resolution:30000 counts.
Accuracy: ±0.2% full scale span or ±1 °C, @ 25 °C and
nominal power supply voltage.
Common Mode Rejection Ratio: 120 dB @ 50/60 Hz.
Inputs
Thermocouples Type: J, K, L, N and T or RTD Pt 100,
keyboard configurable.
Engineering Units: °C and °F keyboard configurable.
Reference Junction: Automatic compensation for
ambient temperature between 0 and 50°C.
Sensor Lead Impedance: 100 Ω maximum for TC input.
RTD Line Resistance: Automatic compensation up to 20
Ω /wire.
Reference Junction Drift: 0.1 °C/°C.
Input Impedance: Greater than 1 MΩ.
Sensor Break: Downscale or upscale programmable.
On RTD inputs, an OVERRANGE is indicated
when input resistance is less than 15 Ω (short
circuit sensor detection.)
Calibration: According to IEC 584-1 and DIN 43710-1977.
Standard Ranges
Input °C °F
L 0 to 800 0 to 999 DIN 43710-1977
J 0 to 800 0 to 999 IEC 584-1
K 0 to 999 0 to 999 IEC 584-1
N 0 to 999 0 to 999 IEC 584-1
Pt100 -19.9 to 99.9 DIN 43760
Pt100 -199 to 500 -199 to 999 DIN 43760
T 0 to 400 0 to 750
Normal Mode Rejection Ratio: 60 dB @ 50/60 Hz.
Operating Temperature: 0 to 50 °C.
Storage Temperature: -20 to 70 °C.
Humidity: From 20 to 85% RH non-condensing.
Protection: 1) Watch dog for automatic reset; 2) DIP
switches for configuration and calibration
parameter protection.
Control Actions
On/off, PID or autotuning (Smart AT)
Special Function: Standby alarm sequence.
