161R5905753 /17 DPxK-19B/23B/P
Image 12–2 Sealed cover, remove
A security warning will be displayed on the projector. Execute the procedure “Authorization to clear
security warning on the projector”.
12.2 Close the sealed compartment
Required tools
3 mm Allen wrench
How to close the sealed compartment
1. Hook the cover plate on the studs.
Image 12–3 Sealed cover, mount
2. Slide the cover downwards by pushing on both lips until it is in its correct position.
3. Drive in both fixation screws (1).
Convergence
