R5905753 /17 DPxK-19B/23B/P26
2.3 Initial inspection
General
Before shipment, the projector was inspected and found to be free of mechanical and electrical defects. As
soon as the projector is unpacked, inspect for any damage that may have occurred in transit. Save all packing
material until the inspection is completed. If damage is found, file claim with carrier immediately. The Barco
Sales and Service office should be notified as soon as possible.
The packaging of the DPxK-19B/23B/P is provided with a shock-watch label. If this shock-watch
label was triggered (red colored at arrival) during transport, indicates that the package was possibly
roughly handled by the transport company. In this case, the instructions mentioned on the label,
should be followed, which are: adding a note on the “bill of lading” and informing the transport
company and the Barco sales and service office as soon as possible.
Box content
After unpacking the projector it is recommended to check if all following items where included:
• One short power link cable (mono phase) (in case no UPS is used) - Installed on projector.
• This manual (installation manual).
• Safety manual
The projector lens and xenon lamp are not included in the package of the projector.
Mechanical check
This check should confirm that there are no broken knobs or connectors, that the cabinet and panel surfaces
are free of dents and scratches, and that the operating panel is not scratched or cracked. The Barco Sales
and Service office should be notified as soon as possible if this is not the case.
Tamper labels
During installation please inspect the tamper labels, if they are damaged please contact Barco tech support.
The tamper labels are required by DCI to provide easy visual indication if the equipment was tampered with.
The projectors are tested and labeled for shipping to ensure that the system was not compromised before
reaching the customers final destination.
These tamper labels can be found behind the input cover. See “Removal of the input cover”, page 141.
2.4 Installation process overview
Let the projector acclimate to the ambient temperature after unpacking. Neglecting this may result in
a startup failure of the light processor unit.
Set up from A to Z
After you have unpacked and checked the projector, you can start with the installation process of your DPxK
B. This chapter gives you an overview of all the different stages in the installation process which you have to
follow to set your DPxK B up and running. Each stage is briefly described and refers to more detailed step by
step procedures in this manual. Use this overview as a checklist to ensure that you have followed all stages in
the setup process of your DPxK B.
Set up from A to Z
1. Check if all installation requirements are fulfilled such as the environment conditions of the installation
area, capacity of the exhaust system, electrical facilities, etc. Note that a solid pedestal is required to
support the projector head. For more info see topic “Installation requirements”, page 22.
