R5905753 /17 DPxK-19B/23B/P170
equivalent throw ratios for 4K 1.38" DMD
Control I/O 3x Ethernet (RJ 45)<br8x GPIO (DB 25)
3D interface
USB RS-232 interface
Integrated Cinema Media
Processor
DCI 4K 2D up to 60fps
DCI 4K 3D (24 or 30 fps per eye)
DCI High Frame Rates 2K 3D up to 120fps (60fps per eye)
JPEG 2000 bit-rates up to 625Mbps
Dual-channel color-correction
MPEG-2 (4:2:0 and 4:2:2 up to 60fps)
2x HDMI2.0a (up to 4K 2D 60fps)
2x 3G-SDI inputs
16x AES/EBU audio channels (2x RJ45)
8x GPI, 8x GPO (4x RJ45)
2x Gbe for content connectivity & ingest
2x front-accessible USB 3.0 for fast ingest
2x front-accessible USB 2.0
Video watermarking: Civolution NexGuard
Audio watermarking: Civolution
Closed captioning devices: Support for SMPTE 430-10
** On B&C series projectors, the DisplayPort inputs replace the DVI inputs
of the Cinema Controller.
Integrated storage 1.9TB effective storage (RAID-5) / 3x 1TB Hot-swappable 2.5" hard-drives
3.9TB effective storage (RAID-5) / 3x 2TB Hot-swappable 2.5" hard-drives
Barco Web Commander Projector Dashboard
Projector Control Board
Show Player/Editor/Scheduler
Automation, 3D, Ingest
Dynamic DCP playlists & intermission
TMS integration
Smart Projector Status
Via HTML5 web-browsers including iOS & Android tablets
Dual projector 3D: passive and active
Auro 11.1 decoding
Power requirements 200-240V, 50-60Hz, 24A
19,000 BTU/hr (with 4kW lamp)
Dimensions 604(H) x 754(W) x 1129(D) mm / 23.78(H) x 29.69(W) x 44.45(D) inch
NB.: min. 5 cm of air inlet spacing required at the bottom of projector
Weight 134 kg (295 lbs)
Ambient temperature 35°C / 95°F Max.
Exhaust airflow 350 – 390 cfm (10 – 11 m³/min)
Specifications
