Barco DP2K-23B User Manual

R5905753 /17 DPxK-19B/23B/P24
foam. Once the projector has arrived at the installation site, it needs to be removed from the carton box and
wooden pallet in a safe manner without damaging the projector.
After unpacking let the projector acclimatises to a room temperature higher then 10°C (50°F) and
lower then 35°C (95°F). Neglecting this may result in a start up failure of the Light Processor Unit.
How to unpack
1. Loosen the banding by pulling the free end of the banding loop in the clip.
Take off the box cover.
Image 2–2 Open banding
2. Open the box.
Take out the small box between the outer and inner box containing the manuals.
Remove the outer carton box
Image 2–3 Remove outer carton
General

Barco DP2K-23B Specifications

General

Contrast ratio (typical)	2000:1
Projector native resolution	2K (2048x1080)
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	3
AC input voltage	200 - 240 V
Lamp power	4000 W

Weight and Dimensions

Depth	754 mm
Width	604 mm
Height	1129 mm
Weight	133000 g
