68 Display Controller
MXRT 7300
Bus PCI Express Gen2 x16 native support
Dimensions 249 mm (L) x 111 mm (H) (9.8” x 4.375”) single PCIe
slot wide
Operating system Windows®, XP 32/64 bit Server 2003, 2008,
Windows 7 32/64 bit XPDM, WDDM
Platforms Intel® and AMD architectures
Graphics accelerator ATI FirePro (RV730 GL XTX GPU)
Memory 1GB GDDR3
Look up table 24-bits in / 24-bits out (8-bits per color channel)
Pixel depth 24-bit / 30-bit (HDR mode)
Electrical standard Dual-link DVI, DisplayPort complying to v1.0
specification
Video output 2- DisplayPort connectors, 1- DL DVI-I connector
Standard resolutions Up to 3280 x 2048 (VGA at boot-up)
Approvals FCC Part 15 Class B, CE EN 55022 Limit B, EN 55024,
UL-60950-1, BMSI CNS, CISPR-22/24, VCCI, CSA C22.2,
EU RoHS directive (2002/95/EC), Certificate of
Information & Communication Equipment (Republic of
Korea)
Operating temperature
range
0° to 55°C (32° to 131° F)
Power consumption 76 Watts
