Barco G62 - Page 93

93R5914653 /02 G62
Level 2 Level 3 Level 4 Level 5 Level 6 Default Uart Command
Bottom
Right
Horizontal
0 Bottom Right Horz: [BRCX***]
Vertical
0 Bottom Right Vert: [BRCY***]
Ad-
vanced
Warp
Grid Points
2x2
2x2 [WGPG0]
3x3
[WGPG1]
5x5
[WGPG2]
9x9
[WGPG3]
17x17
[WGPG4]
Warp Inner
Off / On
On [WWIG0] / [WWIG1]
Warp
Sharpness
9
[WWSG*]
Grid Color
Green
Green [WGCG0]
Magenta [WGCG1]
Red
[WGCG2]
Cyan [WGCG3]
Grid
background
Black
Black [WBCG0]
Trans-
parent
[WBCG1]
Blend Setting Blend
Width
[EBLG+BLAJ1]
Overlap
Grid
Number
4 4 [EBLG+OLGN0]
6 [EBLG+OLGN1]
8 [EBLG+OLGN2]
10 [EBLG+OLGN3]
12 [EBLG+OLGN4]
Gamma
1,8
2,2 [EBLG+GAMA0]
1,9
[EBLG+GAMA1]
2
[EBLG+GAMA2]
2,1
[EBLG+GAMA3]
2,2
[EBLG+GAMA4]
2,3
[EBLG+GAMA5]
2,4
[EBLG+GAMA6]
Memory Save
Memory
Memory
1
Memory
1
[GMSG1]
Memory
2
[GMSG2]
Memory
3
[GMSG3]
Memory
4
[GMSG4]
Memory
5
[GMSG5]
Apply
Memory
Memory
1
Memory
1
[GMAG1]
Memory
2
[GMAG2]
Memory
3
[GMAG3]
Memory
4
[GMAG4]
Communication protocols
