Page #1 background image

Loading...

Page #1 background image

Page 1 of 25

WALL MOUNTED

PACKAGED HEAT PUMP

Models:

INSTALLATION INSTRUCTIONS

C24H1-A

C24H1-B

C30H1-A

C30H1-B

C30H1-C

C36H1-A

C36H1-B

C36H1-C

C42H1-A

C42H1-B

C42H1-C

Bard Manufacturing Company, Inc.

Bryan, Ohio 43506

www.bardhvac.com

Manual: 2100-586D

Supersedes: 2100-5486C

Date: 7-28-15

C48H1-A

C48H1-B

C48H1-C

C60H1-A

C60H1-B

C60H1-C

Table of Contents

Questions and Answers:

N
Nicole JacksonAug 16, 2025
Why is the outdoor fan motor not running on my Bard Heat Pump (cooling or heating except during defrost)?
- T
  Tyler LarsenAug 16, 2025
  If the outdoor fan motor on your Bard Heat Pump isn't running, it could be due to a few reasons. The heat pump control might be defective; check across the fan relay on the heat pump control (Com-NC) and consider replacing the heat pump control. The motor itself could be defective, so check for open or shorted motor windings and replace the motor if necessary. Alternatively, the motor capacitor might be defective, so check the capacitor rating and look for open or shorted capacitors, replacing the capacitor if needed.
S
stacy57Aug 23, 2025
What to do if the reversing valve does not energize on my Bard Heat Pump (heating only)?
- W
  Wayne KeithAug 23, 2025
  If the reversing valve isn't energizing on your Bard Heat Pump, first check for 24V between RV-C and B-C. Make sure to check the control circuit wiring. If that's not the issue, the reversing valve solenoid coil might be defective, so check for an open or shorted coil and replace it if necessary.
A
angela31Aug 28, 2025
How to troubleshoot if my Bard Heat Pump will not go into defrost (heating only)?
- W
  William DavisAug 28, 2025
  If your Bard Heat Pump isn't going into defrost, it could be due to a defective temperature sensor or heat pump control. Try disconnecting the temperature sensor from the board and use a jumper across the "SPEEDUP" and "SEN JMP" terminals. This should initiate a defrost cycle within one minute. If it goes through defrost, replace the temperature sensor. If it doesn't, replace the heat pump control.
I
ibowersSep 4, 2025
What to do if my Bard Heat Pump unit will not come out of defrost (heating only)?
- D
  Darren SerranoSep 4, 2025
  If your Bard Heat Pump won't come out of defrost, the temperature sensor or heat pump control might be defective. Try using a jumper across the "SPEEDUP" terminal. This should cause the unit to exit defrost within one minute. If the unit comes out of defrost, replace the temperature sensor. If it doesn't, replace the heat pump control.

Bard C24H1-A Specifications

General

Model Number	C24H1-A
Category	Heat Pump
SEER	16
Voltage	208/230V
Refrigerant	R-410A
Cooling Capacity	24, 000 BTU/h
Heating Capacity	24, 000 BTU/h
Power Supply	1 Phase, 60 Hz
Sound Pressure Level (Outdoor Unit)	56 dBA

Related product manuals

Preview: Bard C36H1-A

Preview: Bard CH Series

Preview: Bard I30H1

Preview: Bard W42HC-A

Preview: Bard 11EER WH Series

Bard 11EER WH Series
