Manual 2100-746D

Page 40 of 59

303 System 3 - Y2 - Compressor - Stage 2 bit 0 (OFF) - 1 (ON)

305 System 3 - G - Blower bit 0 (OFF) - 1 (ON)

306 System 3 - O/B - Reversing Valve bit 0 (OFF) - 1 (ON)

307 System 3 - A Terminal bit 0 (OFF) - 1 (ON)

308 System 3 - D - Mechanical Dehum bit 0 (OFF) - 1 (ON)

309 System 3 - H - Humidier bit 0 (OFF) - 1 (ON)

310 System 3 - AUX - Auxiliary Terminal bit 0 (OFF) - 1 (ON)

311 System 3 - Change Filter bit 0 (OFF) - 1 (ON)

312 System 3 - Power Loss bit 0 (OFF) - 1 (ON)

313 System 3 - Compressor Lockout bit 0 (OFF) - 1 (ON)

314 System 3 - Dust bit 0 (OFF) - 1 (ON)

400 System 4 - W1 - Electric Heat - Stage 1 bit 0 (OFF) - 1 (ON)

401 System 4 - W2 - Electric Heat - Stage 2 bit 0 (OFF) - 1 (ON)

402 System 4 - Y1 - Compressor - Stage 1 bit 0 (OFF) - 1 (ON)

403 System 4 - Y2 - Compressor - Stage 2 bit 0 (OFF) - 1 (ON)

405 System 4 - G - Blower bit 0 (OFF) - 1 (ON)

406 System 4 - O/B - Reversing Valve bit 0 (OFF) - 1 (ON)

407 System 4 - A Terminal bit 0 (OFF) - 1 (ON)

408 System 4 - D - Mechanical Dehum bit 0 (OFF) - 1 (ON)

409 System 4 - H - Humidier bit 0 (OFF) - 1 (ON)

410 System 4 - AUX - Auxiliary Terminal bit 0 (OFF) - 1 (ON)

411 System 4 - Change Filter bit 0 (OFF) - 1 (ON)

412 System 4 - Power Loss bit 0 (OFF) - 1 (ON)

413 System 4 - Compressor Lockout bit 0 (OFF) - 1 (ON)

414 System 4 - Dust bit 0 (OFF) - 1 (ON)

500 System 5 - W1 - Electric Heat - Stage 1 bit 0 (OFF) - 1 (ON)

501 System 5 - W2 - Electric Heat - Stage 2 bit 0 (OFF) - 1 (ON)

502 System 5 - Y1 - Compressor - Stage 1 bit 0 (OFF) - 1 (ON)

503 System 5 - Y2 - Compressor - Stage 2 bit 0 (OFF) - 1 (ON)

505 System 5 - G - Blower bit 0 (OFF) - 1 (ON)

506 System 5 - O/B - Reversing Valve bit 0 (OFF) - 1 (ON)

507 System 5 - A Terminal bit 0 (OFF) - 1 (ON)

508 System 5 - D - Mechanical Dehum bit 0 (OFF) - 1 (ON)

509 System 5 - H - Humidier bit 0 (OFF) - 1 (ON)

510 System 5 - AUX - Auxiliary Terminal bit 0 (OFF) - 1 (ON)

511 System 5 - Change Filter bit 0 (OFF) - 1 (ON)

512 System 5 - Power Loss bit 0 (OFF) - 1 (ON)
