Manual 2100-746D
Page 41 of 59
513 System 5 - Compressor Lockout bit 0 (OFF) - 1 (ON)
514 System 5 - Dust bit 0 (OFF) - 1 (ON)
600 System 6 - W1 - Electric Heat - Stage 1 bit 0 (OFF) - 1 (ON)
601 System 6 - W2 - Electric Heat - Stage 2 bit 0 (OFF) - 1 (ON)
602 System 6 - Y1 - Compressor - Stage 1 bit 0 (OFF) - 1 (ON)
603 System 6 - Y2 - Compressor - Stage 2 bit 0 (OFF) - 1 (ON)
605 System 6 - G - Blower bit 0 (OFF) - 1 (ON)
606 System 6 - O/B - Reversing Valve bit 0 (OFF) - 1 (ON)
607 System 6 - A Terminal bit 0 (OFF) - 1 (ON)
608 System 6 - D - Mechanical Dehum bit 0 (OFF) - 1 (ON)
609 System 6 - H - Humidier bit 0 (OFF) - 1 (ON)
610 System 6 - AUX - Auxiliary Terminal bit 0 (OFF) - 1 (ON)
611 System 6 - Change Filter bit 0 (OFF) - 1 (ON)
612 System 6 - Power Loss bit 0 (OFF) - 1 (ON)
613 System 6 - Compressor Lockout bit 0 (OFF) - 1 (ON)
614 System 6 - Dust bit 0 (OFF) - 1 (ON)
