Standard AES/EBU input with 0.2 Vpp sensitivity (6.8 Vpp max).
Standard AES/EBU output providing typically 5 Vpp signal into 110 Ohm load.
Standard RS-232 and RS-485 serial interfaces:
Parameter RS-232 RS-485
Signals RxD, TxD, RTS, CTS,
GND
A, B, Reference, Shield
Baud rates 300 .. 230400 300 .. 230400
Data bits 7 or 8 7 or 8
Parity No, Even, Odd No, Even, Odd
Stop bits 1 or 2 1 or 2
Flow control No, XON/XOFF,
RTS/CTS
No, XON/XOFF,
RTS/CTS
Power for external devices + 14.6 V
100mA max.
-
Standard Ethernet network interface, RJ-45 socket. 10/100 Mbit, full / half duplex, auto negotiation.
The four inputs are TTL level dry-contact closures inputs (pull-up to 5V by 10 K-Ohm).
The four outputs are closing relays (normally open), rated 24 V 0.5 A.
Power supply input range from 24 to 48 VDC ±20% with a maximal consumption of 8 Watts.
The Reset push button, available on the front, allows for resetting the device (brief push) and reverting to
factory defaults (push approx. 10 sec.)
216 x 38 x 125 mm (Width, Height, Depth) / 8½” x 1½” x 5”.
The three D-sub 9 pin connectors stand out and increase the overall depth to 131mm / 5¼”.
620 grams / 21.87 oz. (without any cables).
32 ~ 104° F / 0 ~ 40° C, < 70% relative humidity (non-condensing)
BARIX AG |
9
/
14
Weight
Dimensions
Reset Button
Network
Interface
Peripheral I/O
Interface
Power supply
Environmental
conditions
Digital audio
Serial
Interfaces
