Barnes SE Series - Pump Specifications; 2-Inch Pump Details; 3-Inch Pump Details

SECTION: A- PUMP SPECIFICATIONS
2" Pumps (Standard & High Temperature)
3" Pumps
DISCHARGE: 2" (51mm) NPT, Vertical.
TEMPERATURE:
Standard 104°F (40°C) Continuous.
High Temp. 200°F (93°C) Continuous.
VOLUTE: Cast Iron ASTM A-48, Class 30.
MOTOR HOUSING: Cast Iron ASTM A-48, Class 30.
SEAL PLATE: Cast Iron ASTM A-48, Class 30.
IMPELLER:
Design: 2 Vane, Open, With Pump Out
Vanes On Back Side. Dynamically
Balanced, ISO G6.3.
Material: Cast Iron ASTM A-48 Class 30.
SHAFT: 416 Stainless Steel
SQUARE RINGS: Buna-N
HARDWARE: 300 Series Stainless Steel
PAINT: Air Dry Enamel.
SEAL: Design: Single Mechanical, Oil Filled
Reservoir.
Material: Rotating Faces - Carbon
Stationary Faces - Ceramic
Elastomer - Buna-N
Hardware -300 Series Stainless
CABLE ENTRY: 15ft. (4.5M) Cord, Plug on 115
Volt, Pressure Grommet for
Sealing and Strain Relief.
SPEED: 1750 RPM (Nominal).
UPPER BEARING:
Design: Sleeve
Lubrication: Oil
Load: Radial
LOWER BEARING:
Design: Single Row, Ball
Lubrication: Oil
Load: Radial & Thrust
MOTOR:
Design: NEMA L Torque Curve. Completely
Oil-Filled, Squirrel Cage Induction.
Insulation: Standard - Class A .
High Temp. - Class B
SINGLE PHASE: Permanent Split Capacitor (PSC).
Includes Overload Protection in Motor.
FLOAT: Automatic Models. Wide Angle,
Ploypropylene, 15ft (4.5M) Cable on
SE51A, SE51HTA, with Piggy-Back
Plug. SE51AU, SE51HTAU, SE52AU
& SE52HTAU Float Attached to Pump.
ON and OFF Points are Adjustable.
OPTIONAL EQUIPMENT: Seal Material, Impeller Trims,
Additional Cable, *Inlet Strainer for
High Temperature Models.
* 3/4" Spherical solids handling with optional inlet strainer.
DISCHARGE: 3 " (76mm) NPT, Vertical.
TEMPERATURE: 104°F (40°C) Continuous.
VOLUTE: Cast Iron ASTM A-48, Class 30.
MOTOR HOUSING: Cast Iron ASTM A-48, Class 30.
SEAL PLATE: Cast Iron ASTM A-48, Class 30.
IMPELLER:
Design: 2 Vane, Open, With Pump Out
Vanes On Back Side. Dynamically
Balanced. ISO G6.3.
Material: Cast Iron ASTM A-48 Class 30.
SHAFT: 416 Stainless Steel
SQUARE RINGS: Buna-N
HARDWARE: 300 Series Stainless Steel
PAINT: Air Dry Enamel.
SEAL: Design: Single Mechanical, Oil Filled
Reservoir.
Material: Rotating Face - Carbon
Stationary Face - Ceramic
Elastomer - Buna-N
Hardware - 300 Series Stainless
CABLE ENTRY: 15ft. (4.5M) Cord (Plug On 115 Volt),
Pressure Grommet For Sealing And
Strain Relief.
SPEED: 1750 RPM (Nominal).
UPPER BEARING:
Design: Sleeve
Lubrication: Oil
Load: Radial
LOWER BEARING:
Design: Single Row, Ball
Lubrication: Oil
Load: Radial & Thrust
MOTOR:
Design: NEMA L-Single Phase,
NEMA B-Three Phase Torque Curve.
Completely Oil-Filled, Squirrel
Cage Induction.
Insulation: Class A .
SINGLE PHASE: Permanent Split Capacitor (PSC).
Includes Overload Protection In Motor.
THREE PHASE: Tri Voltage 200-230/460;
Requires Overload Protection to be
Included In Control Panel.
OPTIONAL EQUIPMENT: Seal Material, Impeller Trims, N/C
Temperature Sensor with cable for 3 phase pumps,
Additional Cable, CSA Listing on 3 phase pumps.
4
