MODEL HP VOLT PH RPM NEMA FULL LOCKED CORD CORD CORD EMERSON G.E.
NO. (Nom) CODE LOAD ROTOR SIZE TYPE OD WINDING WINDING
AMPS AMPS RESISTANCE RESISTANCE
MAIN--START MAIN--START
SE51 .50 115 1 1750 D 11.6 18.4 14/3 SJTOW-A 0.390 1.18--14.25 1.34--16.88
SE51A .50 115 1 1750 D 11.6 18.4 14/3 SJTOW-A 0.390 1.18--14.25 1.34--16.88
SE51AU .50 115 1 1750 D 11.6 18.4 14/3 SJTOW-A 0.390 1.18--14.25 1.34--16.88
SE52 .50 230 1 1750 E 5.8 10.5 14/3 SJTOW-A 0.390 4.67--10.72 4.15--11.84
SE52A .50 230 1 1750 E 5.8 10.5 14/3 SJTOW-A 0.390 4.67--10.72 4.15--11.84
SE52AU .50 230 1 1750 E 5.8 10.5 14/3 SJTOW-A 0.390 4.67--10.72 4.15--11.84
SE51HT .50 115 1 1750 J 17.0 40.0 14/3 SOO 0.560 *
SE51HTA .50 115 1 1750 J 17.0 40.0 14/3 SOO 0.560 *
SE51HTAU .50 115 1 1750 J 17.0 40.0 14/3 SOO 0.560 *
SE52HT .50 230 1 1750 E 8.5 20.0 14/3 SOO 0.560 *
SE52HTA .50 230 1 1750 E 8.5 20.0 14/3 SOO 0.560 *
SE52HTAU .50 230 1 1750 E 8.5 20.0 14/3 SOO 0.560 *
3SE514L .50 115 1 1750 A 11.6 18.4 14/3 SJTOW-A 0.390 1.18--14.25 1.34--16.88
3SE524L .50 230 1 1750 A 5.8 10.5 14/3 SJTOW-A 0.390 4.67--10.72 4.15--11.84
3SE594L .50 200-230 3 1750 A/B 3.9/3.4 6.8/7.8 14/4 SO 0.600 13.87-- 14.06--
3SE544L .50 460 3 1750 B 1.7 3.9 14/4 SO 0.600 55.48-- 56.24--
3SE554L .50 575 3 1750 B 1.3 3.1 14/4 SO 0.600 21.96--
3SE724L .75 230 1 1750 A 8.9 17.5 14/3 SJTOW-A 0.390 2.24--9.24 2.32--9.22
3SE794L .75 200-230 3 1750 B/E 5.1/4.4 13.9/16 14/4 SO 0.600 6.00-- 6.10--
3SE744L .75 460 3 1750 E 2.2 8.0 14/4 SO 0.600 24.00-- 24.40--
3SE754L .75 575 3 1750 E 1.7 6.4 14/4 SO 0.600 9.53--
3SE1024L 1.0 230 1 1750 A 10.9 17.5 14/3 SJTOW-A 0.390 2.24--9.24 2.32--9.22
3SE1094L 1.0 200-230 3 1750 A/B 6.8/6.0 13.9/16 14/4 SO 0.600 6.00-- 6.10--
3SE1044L 1.0 460 3 1750 B 3.0 8.0 14/4 SO 0.600 24.00-- 24.40--
3SE1054L 1.0 575 3 1750 B 2.4 6.4 14/4 SO 0.600 9.53--
Winding Resistance ± 5%
Pump Rated for Operation at ± 10% Voltage at Motor.
2" Pumps ONLY.
Mercury Switch on SE51A & Mechanical on SE52A, Cable 16/2, SJOW-A, 0.320 O.D. Piggy-Back Plug.
Mechanical Switch on SE51AU & SE52AU, Cable 14/2, SJOOW-A (UL), SJOW (CSA), 0.370 O.D.
3" Pumps ONLY.
Standard Units:
Optional - Temperature sensor cable for 3 phase models is 14/2 SOW-A, 0.530 O.D.
CSA Listed Units:
Optional - CSA Listed Power Cable for 3 Phase Models is 14/4 SOW-A, 0.600 O.D.
Optional - CSA Listed Temperature Sensor Cable for 3 Phase Models is 14/2 SOW-A, 0.530 O.D.
* These motors are manufactured by Franklin Electric. When checking winding resistance of these motors, disconnect leads to solid state switch.
Once leads have been disconnected, resistance should read as follows: (2MAINS) Yellow & Blue = 1.79 ohms; Grey & Orange = 1.79 ohms,
(START WINDINGS) Red & Orange = 5.99 ohms.
D-3) Start-Up Report:
Included at the end of this manual are two start-up report sheets,
these sheets are to be completed as applicable. Return one copy to
Barnes Pumps, Inc. and store the second in the control panel or with
the pump manual if no control panel is used. It is important to record
this data at initial start-up since it will be useful to refer to should
servicing the pump be required in the future.
D-3.1) Identification Plate:
Record the numbers from the pump identification plate on both
START-UP REPORTS provided at the end of the manual for future
reference.
D-3.2) Insulation Test:
Before the pump is put into service, an insulation (megger) test
should be performed on the motor. The resistance values (ohms) as
well as the voltage (volts) and current (amps) should be recorded
on the start-up report.
D-3.3) Pump-Down Test:
After the pump has been properly wired and lowered into the basin,
sump or lift station, it is advisable to check the system by filling with
liquid and allowing the pump to operate through its pumping cycle.
The time needed to empty the system, or pump-down time along
with the volume of water, should be recorded on the start-up report.
