Installation
29
Operating Instructio
ns Radiation
sensors R3
XX
Connection to T
R 40-
10
Sensor connection
Pin
Signal
Colour
1
2
3
4
5
6
-
-
R+
R-
U-
U+
-
-
red
orange
black
brown
Disc
Shield
Shield,
14 mm, stripped
Cable gla
nd
4...20 mA
–
+
Shield
32
34
