Operation
32
Operating Instructions Radiation sensors R3XX
4.2.1 Configuration with transmitter TR 41-10
Sensors R 310, R 311, R 312 and R 320 can be configured using a
connected transmitter, Type TR 41-10.
4.2.1.1 Configuration process
Starting configuration mode
In order to start configuration, press the mode button .
Selecting parameters
Each time you press the mode button , you branch to the next parameter.
Changing parameters
You can use the and buttons to increase or decrease the entered
values one value at a time. You can also hold down the respective button,
with the result that the value will change slowly to begin with and then speed
up. The value will be saved when you proceed to the next parameter using
the mode button .
Quitting configuration mode
You quit configuration mode when you press the mode button for the final
parameter. Measurement operation will be continued with the changed
parameters.
If no button is pressed for around 20s during configuration mode, the system
will automatically return to measurement operation. All changes made to
parameters up to then will also be adopted.
