Operation
34
Operating Instructions Radiation sensors R3XX
Maximum mode
A “hold time” for maximum values is set here. The maximum value that has
occurred in each case is held for the set time and output. If a new maximum
value occurs during the hold time, the hold time will begin all over again.
The time is set in seconds.
Display
P
Minimum value
0.0
Maximum value
999.9
Increment
0.1
Default value
0.0
Minimum mode
A “hold time” for minimum values is set here. The minimum value that has
occurred in each case is held for the set time and output. If a new minimum
value occurs during the hold time, the hold time will begin all over again.
The time is set in seconds.
Display
M
Minimum value
0.0
Maximum value
999.9
Increment
0.1
Default value
0.0
Example
Example
t
h
Hold time
Actual temperature pattern
Temperature pattern that is output
P 0.0
M 0.0
