In order to prevent damage to the flexible cable, the following points should be considered for the final
pump assembly
- the flexible connector must not be bent around sharp edges or kinked
- the flexible connector must not be bend on top or bottom of the pump
- the Molex connector is not water tight, additional sealing of both pump and connector
with e.g. silicone might be necessary
- fixation of the Molex connector in the final assembly is recommended
4.2 Cleaning the system
The pump can be washed with water, alcohol (iso-propanol) or if necessary with weak acid by pumping or
by flushing with the help of a syringe.
!! Only use the syringe pulling from the outlet in pumping direction!!
