Installation and connection– 52
Pin assignment on the outdoor panel:
GND: Ground.
12V: Power supply + 12 Volts.
485A: RS485 Data +.
485B: RS485 Data -.
DoorA-DoorE: Controlled inputs (dry contacts). It is possible to use for connecting the exit
buttons and door sensors, and fire alarm sensors as well, if connected to the corresponding bus.
GNDA-GNDE: Ground for controlled inputs.
D0: Contact Data 0 for Wiegand.
D1: Contact Data 1 for Wiegand.
GND: Ground for Wiegand.
GND: Ground for locks.
R_A_NO: Normally open contact for 1 relay.
R_A_COM: Switchable contact for 1 relay.
R_A_NC: Normally closed contact for 1 relay.
R_B_NO: Normally open contact for 2 relay.
R_B_COM: Switchable contact for 2 relay.
R_B_NC: Normally closed contact for 2 relay.
Mechanical mounting
Surface mounting
1. Make a hole in the wall of the following sizes 70X65X50 mm. It will serve for placing of all
cable connections.
