Technical parameters– 8
Technical parameters
General parameters
Panel type:Individual
Screen:No
Matrix size:1/4’’
Angle:122° horizontal x 70° vertical
Matrix resolution:1 MP
Output video:720p (1280x720) H.263, H264, MJPEG
Night backlight:4 IR LEDs
Light sensitivity:0.01 lux
Protection class:IP65
Operating temperature:-40 - +65 °C
Power consumption:6.5 W, in standby – 4 W
Power:+12 V, PoE
Body:Metal
Colors:Silver gray, black
Dimensions for installation:165x108x65 mm
Dimensions of panel:168x115x40mm
Installation: Flush mounting, wall mounting with BR-AV7
Functional capabilities
Interface:WEB-interface
Lock opening:By card, with the monitor
AV-07T access control:Combined contactless card reader: EM-Marin and MIFARE
AV-07B access control:Multiformat UKEY reader (Em-Marin, Mifare, Bluetooth, NFC)
Integration with ACS:Wiegand-26, Wiegand-34 Input / Output
Quick dial buttons: 1 piezoelectric ring button
Number of ringtones:1 polyphonic ringtone
Authentication:A separate password for the settings, WEB-interface
Talking mode:Duplex
Talking time:Up to 30 minutes
