Configuring the Camera
Basler IP Camera 53
To upload a saved configuration file on your PC to the camera, follow the
steps below. When you upload the file, the parameters in the uploaded file
will overwrite the current parameter settings in the camera.
1. Click the Config Management button.
2. A Configuration Management dialog box will open as shown below. Click
the Browse button in the dialog box.
3. A Choose File dialog box will open as shown below. Navigate to the
location of the saved file, select the file, and click the Open button.
4. Click the Restore Config button in the Configuration Management dialog
box.
5. The file will be uploaded from the PC to the camera. When the Are you
sure? message window appears, click the Ye s button.
6. The parameters in the file will be applied to the camera and the web
client will restart. When the restart is done, the procedure is complete.
