Basler SCP 250 User Manual

SECTION 2 • CONTROLS
CONTROLS ILLUSTRATION AND DESCRIPTION
SCP 250 controls are shown in Figure 2-1 and described in Table 2-1.
Figure 2-1. SCP 250 Controls
Table 2-1. Description of SCP 250 Controls
Locator Control Description
A Mode Switch. This switch selects between var and power factor control.
When the mode switch is in the VAR position, the desired reactive power level is
established with the Var/Power Factor Adjust control. The var level is then held constant
and will not vary if changes in watt load occur.
When the mode switch is in the Power Factor position, the desired power factor is
established using the Var/Power Factor Adjust control. The power factor is held constant
even if watt load varies.
911000099Y Rev T SCP 250 Controls 2-1
