Basler SCP 250 User Manual

911000099Y Rev T SCP 250 Installation 4-1
SECTION 4 • INSTALLATION
GENERAL
Upon receipt of an SCP 250, check the part number against the requisition and packing list for
agreement. Inspect for damage, and if there is evidence of such, file a claim with the carrier and notify the
Basler Electric regional sales office, your sales representative, or a sales representative at Basler Electric,
Highland, Illinois.
MOUNTING
The SCP 250 is intended for back-of-the-panel mounting in any plane. It should not be installed in a
location where ambient operating temperature exceeds the range of –40 to 70°C (–40 to 158°F).
SCP 250 dimensions are shown in Figure 4-1. All terminal screws are 6-32 on 0.375 inch (9.5 millimeter)
centers. Drawing dimensions are shown in inches with millimeters in parenthesis.

Basler SCP 250 Specifications

General

Brand	Basler
Model	SCP 250
Category	Controller
Language	English
