www.batcafitness.com 25 Omega 4 Owner’s Manual
Item # Part # Description Qty
57 BFP-10948 Back Chrome Adjustment 1
58 BFP-10867 Leg Ext/Leg Curl Arm 1
59 BFP-52201 Knee Hold Down Cam 1
60 BFP-51874 6” Counter Weight 1
82 BFP-51885 Red Pivot Point Cap 1
88 BFP-52372 SHCS 5/16” x 1/2” 2
91 BFH-50620 BHSCS 3/8” x 1” 1
99 BFP-52382 SHCS 3/8” x 2 1/2” 2
107 BFP-52364 SHCS 3/8” x 6” 1
111 BFH-50146 3/8” Flat Washer 5
112 BFH-50157 3/8” Nylock 2
All Flat Washers and Nylocks are 3/8”
unless otherwise noted.
Step 15:
Figure 15
