www.batcafitness.com 33 Omega 4 Owner’s Manual
Item # Part # Description Qty
113 BFP-52130 Large Bottom Pad 1
114 BFP-52129 Mid Row Chest Pad 1
115 BFU-10121 7” Upholstery Roller 2
71 BFC-50122 Ab Strap 1
72 BFC-50125 Lat Bar 1
73 BFC-50126 Short Bar 1
83
16xBFC-50128
16 Link Chain 1
84
2xBFC-50128
2 Link Chain 1
85 BFH-50622 Large Aluminum End Cap 2
86 BFH-50188 Snap hook 4
89 BFP-52430 BHSCS 3/8” x 3/4” 2
95 BFP-51653 SHCS 3/8” x 1 1/4” 4
109 BFH-50147 3/8” Lock Washer 4
111 BFH-50146 3/8” Flat Washer 4
All Flat Washers and Nylocks are 3/8”
unless otherwise noted.
Step 23:
Figure 23
