Batca omega 4 - 3;8 Lock Washer

Batca Fitness Systems 38 Omega 4 Owner's Manual
All Flat Washers and Nylocks are
3/8” unless otherwise noted.
Item # Part # Description Qty
146 BFP-52137 Head Pad 1
147 BFP-52136 Back Pad With Lumbar 1
148 BFP-52130 Large Bottom Pad 1
158 BFP-51750 SHCS 3/8” x 2 3/4” 2
159 BFP-51747 SHCS 3/8” x 3” 2
160 BFP-51748 SHCS 3/8” x 3 1/4” 2
163 BFH-50157 3/8” Lock Washer 6
165 BFH-50146 3/8” Flat Washer 6
Step 28:
Figure 28
