Batca Fitness Systems 26 Omega 4 Owner's Manual
All Flat Washers and Nylocks are
3/8” unless otherwise noted.
Item # Part # Description Qty
61 BFP-10857 Back Support Tube 1
62 BFP-52135 Anti-Deflection Plate 1
63 BFP-10870 Knee Hold Down Assembly 1
64 BFP-51909 Axle 1
93 BFH-50144 FHSCS 3/8” x 1” 2
101 BFP-52374 FHSCS 3/8” x 2 3/4” 2
111 BFH-50146 3/8” Flat Washer 2
112 BFH-50157 3/8” Nylock 2
Step 16:
Figure 16
