Batca Fitness Systems 4 Omega 4 Owner's Manual
Upholstery
Cables
Tools Required
 9/16” Wrench
 9/16” Ratchet
 Allen Wrench
Set
 Tape Measure
ITEM
NO.
PART NUMBER DESCRIPTION QTY.
113 BFP-52130 Large Bottom Pad 2
114 BFP-52129 Mid Row Chest Pad 1
115 BFU-10121 7” Upholstery Roller 6
116 BFP-52136 Back Pad With Lumbar 2
117 BFP-52137 Head Pad 2
118 BFP-52141 Bottom Pad 1
119 BFU-10122 17” Upholstery Roller 1
ITEM
NO.
PART NUMBER DESCRIPTION QTY.
120 CAB-14005
Weight Stack to High Swivel Pulley
1
121 CAB-14006
Ab Crunch to Low Pulley
1
122 CAB-14004
Pec Cam to Free Floater
1
123 CAB-14002
Free Floater to Chest Press
1
124 CAB-14003
Weight Stack to Free Floater
1
125 CAB-14001
Weight Stack to Cable Lockout
1
126 CAB-14000
Free Floater to Leg Ext/Leg Curl
Cam
1
Hardware
ITEM
NO.
PART NUMBER DESCRIPTION QTY.
75 BFH-50173 3 1/2” Pulley 3
76 BFH-50174 4 1/2” Pulley 24
77 BFP-52157
4 1/2” Wide Groove Pulley
1
78 BFP-51746 1/2” Pulley Spacer 16
79 BFP-51696 Small Aluminum End Cap 6
80 BFH-50210 Gas Spring 2
81 BFH-50165 1” Snap Ring 4
82 BFP-51885 Red Pivot Point Cap 1
83
16xBFC-50128
16 Link Chain 1
84
2xBFC-50128
2 Link Chain 1
85 BFH-50622 Large Aluminum End Cap 6
86 BFH-50188 Snap hook 4
87 BFH-50221 3” Plastic Washer 4
88 BFP-52372 SHCS 5/16” x 1/2” 3
89 BFP-52430 BHSCS 3/8” x 3/4” 6
90 BFP-52340 SHCS 3/8” x 3/4” 16
91 BFH-50620 BHSCS 3/8” x 1” 5
92 BFP-50245 FHSCS 5/16” x 1” 2
93 BFH-50144 FHSCS 3/8” x 1” 2
94 BFH-50351 1 3/8” Shoulder Bolt 6
95 BFP-51653 SHCS 3/8” x 1 1/4” 6
96 BFH-50145 FHSCS 3/8” x 2” 2
97 BFP-51759 SHCS 3/8” x 2” 6
98 BFP-51752 SHCS 3/8” x 2 1/4” 19
99 BFP-52382 SHCS 3/8” 2 1/2” 3
100 BFP-51750 SHCS 3/8” x 2 3/4” 24
101 BFP-52374 FHSCS 3/8” x 2 3/4” 2
102 BFP-51747 SHCS 3/8” x 3” 14
103 BFP-51748 SHCS 3/8” x 3 1/4” 10
104 BFH-51884 SHCS 3/8” x 4 1/4” 4
105 BFP-51799 SHCS 3/8” x 5” 4
106 BFP-51756 SHCS 3/8” x 5 1/4” 10
107 BFP-52364 SHCS 3/8” x 6” 1
108 BFH-50267 5/16” Nylock 6
109 BFH-50147 3/8” Lock Washer 16
110 BFH-50204 3/8” Curved Washer 30
111 BFH-50146 3/8” Flat Washer 149
112 BFH-50157 3/8” Nylock 89
 1/2” Wrench
 1/2” Ratchet
 3/4” Wrench
 Snap Ring Pliers
