www.batcafitness.com 5 Omega 4 Owner’s Manual
Leg Press Components
ITEM
NO.
PART NUMBER DESCRIPTION QTY.
127 BFP-10963 Leg Press Base
Connector
1
128 BFM-50260 Guide Rod 2
129 BFM-10299 Top Weight Plate 1
130 BFM-50256 Weight Stack Plate 19
131 BFP-52143 Rubber Donut 2
132 BFP-10965
Guide Rod Tube/Cable Lockout
Plate
1
133 BFP-10964 Leg Press Frame 1
134 BFP-10856 Back Chrome Adjustment 1
135 BFP-10860 User Left Handle 1
136 BFP-10861 User Right Handle 1
137 BFP-52159 Anti-Deflection Plate 1
138 BFP-10852 Pivot Arm 1
139 BFP-10851 Four Bars 2
140 BFP-51843 Four Bar Spacer 1
141 BFP-10853 Leg Press Plate 1
142 BFP-10857 Back Support Tube 1
143 BFP-52149 Support Plate 1
144 BFP-10838 Free Floater 1
145 BFM-50345 Pulley Cover 1
170 BFP-11020 Cable Lockout Spacer 1
ITEM NO. PART NUMBER DESCRIPTION
QTY
.
149 BFH-50174 4 1/2” Pulley 7
150 BFP-51696 Small Aluminum End Cap 2
151 BFP-51746 1/2” Pulley Spacer 4
152 BFP-52372 SHCS 5/16” x 1/2” 2
153 BFH-50620 BHSCS 3/8” x 1” 4
154 BFH-50351 1 3/8” Shoulder Bolt 1
155 BFP-51759 SHCS 3/8” x 2” 1
156 BFP-51752 SHCS 3/8” x 2 1/4” 5
157 BFP-52374 FHSCS 3/8” x 2 3/4” 2
158 BFP-51750 SHCS 3/8” x 2 3/4 4
159 BFP-51747 SHCS 3/8” x 3” 2
160 BFP-51748 SHCS 3/8” x 3 1/4” 4
161 BFP-51799 SHCS 3/8” x 5” 2
162 BFH-50267 5/16” Nylock 1
163 BFH-50157 3/8” Lock Washer 6
164 BFH-50204 3/8” Curved Washer 4
165 BFH-50146 3/8” Flat Washer 26
166 BFH-50157 3/8” Nylock 14
Upholstery
ITEM
NO.
PART NUMBER DESCRIPTION QTY.
146 BFP-52137 Head Pad 1
147 BFP-52136 Back Pad With Lumbar 1
148 BFP-52130 Large Bottom Pad 1
Hardware
Cable
ITEM
NO.
PART NUMBER DESCRIPTION QTY.
167 CAB-14007 Free Floater to Leg Press
Lockout
1
168 CAB-14001 Weight Stack to Free
Floater
1
Accessories
ITEM NO. PART NUMBER DESCRIPTION QTY.
169 BFM-51173 Weight Stack Pull Pin 1
