Frame Components
Accessories
ITEM
NO.
PART NUMBER DESCRIPTION QTY.
1 BFP-10949 Omega 4 Base Hub 1
2 BFP-10951 Mid Row/Lat Pull Base 1
3 BFP-10959
Chest Press/Pec Fly Base
1
4 BFP-10956 Leg Ext/Leg Curl Base 1
5 BFP-10960 Chest Press Pole 1
6 BFP-10950 Mid Row Pole 1
7 BFP-52114
Curved Anti-Deflection PLate
1
8 BFP-10962 Pec Top Assembly 1
9 BFP-10952 Top Frame Brace 1
10 BFP-51767
Curved Anti-Deflection Plate
1
11 BFP-52143 Anti-Deflection Plate 1
12 BFP-10953 Guide Rod Holder 3
13 BFP-11018 Back Shroud Connector 1
14 BFM-50260 Guide Rod 6
15 BFM-10299 Top Weight Plate 3
16 BFM-50256 Weight Stack Plate 57
17 BFP-52143 Rubber Donut 6
24 BFP-52138
Shroud With Logo
2
25
BFM-50444a
Shroud 2
26 BFP-10844
Mid Row Arm
1
27 BFP-10846 Knee Hold Down 1
28 BFP-51800
Curved Anti-Deflection
Plate
1
29 BFP-51776 Axle 1
30 BFP-10845 Swivel Pulley Holder 1
31 BFP-10955 Chest Chrome Adjusment 1
32 BFP-10967
Chrome Mid Row Seat
Adjustment
1
33 BFP-10833
Pec Cam (Left)
1
34 BFP-10834 Pec Cam (Right) 1
35 BFP-10831 Pec Arm (Left) 1
36 BFP-10830 Pec Arm (Right) 1
37
BFP-10825rev1
Foot Assist 1
38 BFP-51699 Axle 1
39 BFP-10832R Lower Pec Arm (Right) 1
40 BFP-10832L Lower Pec Arm (Left) 1
41 BFP-10826 Chest Press Arm 1
42 BFP-10837 Pulley Bracket 1
43 BFP-51736 Axle 2
44 BFP-10936
Chest Press Chrome Seat
1
ITEM NO. PART NUMBER DESCRIPTION QTY.
70 BFM-51173 Weight Stack Pull Pin 3
71 BFC-50122 Ab Strap 1
72 BFC-50125 Lat Bar 1
73 BFC-50126 Short Bar 1
74 BFC-50123 Ankle Strap 1
ITEM
NO.
PART NUMBER DESCRIPTION QTY.
45 BFP-10863 Leg Ext/Leg Curl Frame 1
46 BFP-10947 Bearing Housing J Brace 1
47 BFP-52159 Anti-Deflection Plate 1
48 BFP-52164 Anti-Deflection Plate 1
49 BFP-10963
Leg Ext/Leg Curl Frame
Support
1
50 BFP-51836 Curved Anti-Deflection
Plate
1
51 BFP-52132 Anti-Deflection Plate 1
52 BFP-10867 Leg Ext/Leg Curl Cam 1
53 BFP-10872 User Right Handle 1
54 BFP-10873 User Left Handle 1
55 BFP-10871 Flip Knee Roller 1
56 BFP-52177 Axle 1
57 BFP-10948 Back Chrome Adjustment 1
58 BFP-10867 Leg Ext/Leg Curl Arm 1
59 BFP-52201 Knee Hold Down Cam 1
60 BFP-51874 6” Counter Weight 1
61 BFP-10857 Back Support Tube 1
62 BFP-52135 Anti-Deflection Plate 1
63 BFP-10870 Knee Hold Down
Assembly
1
64 BFP-51909 Axle 1
65 BFP-52165 Double Pulley Plate 2
66 BFM-50345 Pulley Cover 2
67 BFP-10838 Free Floater 3
68 BFP-51883 Double Pulley Cover 1
69 BFM-10588 Knee Hold Down Handle 1
