www.batcafitness.com 43 Omega 4 Owner’s Manual
Adjust cables to proper tension from any of the locations shown below.
Note: All cables with threaded adjustable ends must have at least 1/2” of the threads
threaded in to its counterpart. It is very important that the 1/2” Jam Nut be wrench tight-
ened to the counterpart to ensure that the threaded adjustable end of the cable does not
back out of its counterpart.
Note: If the top plate raises off of the second plate in the weight stack, then the cable ten-
sion is too tight. You will need to take some of the tension out to lower the Top plate flush
with the second plate.
Cable Adjustments
1
2
3
4
