Operating Instructions
Level measurement
CleverLevel
®
LBFS
Point level detection
11. Cleaning, maintenance and repair
Cleaning
f
Clean, disinfect or sterilize sensor as needed
(CIP/SIP).
Maintenance
Regular maintenance is not required.
Repair
Do not repair the sensor yourself.
f
Send damaged sensor to Baumer.
12. Disposal
f
Do not dispose of in household waste.
f
Separate materials and dispose of in
compliance with nationally applicable
regulations.
13. Accessories
For adapter and other accessories see www.baumer.com.
14. Technical data
Environmental conditions Output signal
Operating temperature range
–40…+85 °C Output type
PNP
NPN
Storage temperature range
–40…+85 °C
Ambient humidity
< 98 % RH,
condensing
Current load
20 mA max.
Short circuit
protection
yes
Protection class
IP67
IP69K (with
appropriate cable)
Voltage drop
PNP: (+Vs –1.5 V) ± 0.5 V,
Rload = 10 kΩ
NPN: (+1.5 V) ± 0.5 V,
Rload = 10 kΩ
Oscillations (sinusoidal)
(EN 60068-2-6)
1.6 mm p-p
(2…25 Hz),
4 g (25…100 Hz),
1 octave / min.
Leakage current
± 100 μA max.
Switching logic
Normally open (NO),
active low
Normally closed (NC),
high enabled
Power supply
Voltage supply range
12…30 V DC
Reverse polarity protection
yes
Current consumption
(without load)
25 mA typ.,
50 mA max.
Cable version
Operating tempera-
ture range
–25…+70 °C (if cable is not
moved)
–5…+70 °C (if cable is
moved)
Power-up time
< 2 s
Features
Repeatability
± 1 mm
Hysteresis
± 1 mm Bending radius min.
r ≥ 10 mm
Response time
0.1 s
Damping
0.0…10.0 s
(congurable)
www.baumer.com
13 / 48
