Operating Instructions
Level measurement
CleverLevel
®
LBFS
Point level detection
Example of mounting with weld-in sleeve ZPW3-321
1
1
1
2
1
2
ZPW3-321
Leakage hole
Example of mounting with weld-in sleeve ZPW2-326 or ZPW2-327
170°
5°5°
5°5°
190°
6. Approvals
The EHEDG certicate is only valid in connection with the appropriate installation
parts. These are marked with the "EHEDG Certied" logo.
The 3-A Sanitary Standard requirements are only met with the appropriate
installation parts. These are marked with the 3-A logo.
Approved for explosion hazard areas when installed as specied. For barriers,
Baumer recommends: PROFSI3-B25100-ALG-LS.
Approved by Underwriter Laboratories (UL) for use in the USA and Canada as an
industrial control device.
Certied by DNV GL for ships and offshore platforms.
Approved as an electronic device for railway applications.
For more information about approvals and certication, please see the product page on www.baumer.com.
8 / 48
www.baumer.com
WHG certified for leakage and overfill protection. All documentation must be available
at the place of use and can be found on the product page on www.baumer.com
WHG
