6.9.11. I&M parameter 65000 block 0
I&M is a concept for uniform identification of field devices and is neither manufacturer nor industry-specific.
For this purpose, the field device provides particular information on an electronic product label.
Readout of block 0 of I&M functions (I&M0) is in line with PROFIBUS Identification & Maintenance Guideline
3502 and DPV2 encoder profile 3162. Data blocks I&M1 to I&M4 are not implemented.
I&M functions are accessed by Slot 0 or Slot 1 and index 255. Access to block I&M0 is by parameter number
65000 (0xFDE8).
Slot 0 of SIEMENS controls is addressed by the diagnosis address of the DP slave, in the example below
4093 (0x0FFD).
DS_WRITE
DP-V1 Header
Called parameter
Value
Example
Function ID
Permanent for DS_Write
0x5F
ID
Slot 0 (diagnosis address DP-Slave)
0x0FFD
Index
255 = 0xFF
0xFF
User data length
4 = 0x04
0x04
Data Unit - Call Header (read):
Example
EXTENDED_
FUNCTION_NUM
0x08 permanent for CALL
0x08
reserved
ever 0x00
0x00
IM_INDEX (hi)
65000 = 0xFDE8
0xFD
IM_INDEX (lo)
65000 = 0xFDE8
0xE8
DS_READ
DP-V1 Header
Called parameter
Value
Example
Function ID
Permanent for DS_Read
0x5E
ID
Slot 0 (Diagnose-Adresse DP-Slave)
0x0FFD
Index
255 = 0xFF
0xFF
Usere data length
68 = 0x44 max.
0x40
Data Unit - Call Header (read):
Example
EXTENDED_
FUNCTION_NUM
0x08 permanent for CALL
0x08
reserved
ever 0x00
0x00
IM_INDEX (hi)
65000 = 0xFDE8
0xFD
IM_INDEX (lo)
65000 = 0xFDE8
0xE8
Data Unit - Body (read):
Byte #
Example
0...9
Header
0x00
10
I&M Block
MANUFACTURER_ID
0x01
11
MANUFACTURER_ID
0x2A
12...31
ORDER_ID (20)
0x20
32...47
SERIAL_NUMBER (16)
0x20
48
HARDWARE_REVISION
0x00
49
HARDWARE_REVISION
0x00
50
SOFTWARE_REVISION (*4)
0x56 = ‘V’
51
SOFTWARE_REVISION
0x31 = ‘1’
