7.3. Encoder operating parameters
Description of operating parameters
Parameter
Significance
Sense of rotation
Behaviour of the output code relating to the shaft’s sense of rotation when looking at
the flange.
CW („clockwise“) = ascending values with clockwise rotation
CCW („counter-clockwise“) = ascending values with counter-clockwise rotation
Resolution
(„Measuring units
per revolution“)
Number of steps per revolution, input in integral steps
Measuring range
(„Total Measuring
Range“)
Total resolution = number of steps per revolution x number of revolutions,
input in integral steps
Steps
The actual encoder position is assigned to a certain position value (referencing)
Operating parameter values
Parameter
Value range
Default setting
Data type
Sense of rotation
CW/CCW
CW
Byte
Resolution
1 to 4096 – magtivo
1 to 8192 – multivo
1 to 262144 – multivoPlus
4096
8192
262144
Unsigned 32
Measuring range
1 to 67108864 (2
26
) – magtivo
1 to 536870912 (2
29
) – multivo
1 to 2147483648 (2
31
) – multivoPlus
67108864
536870912
2147483648
Unsigned 32
Peset value
0 to (measuring range - 1 step)
0
Unsigned 32
