Baumer Electrical connection of the process display | 4
V1 | PA408 Operating Manual 11
2 wire sensor
+OUT
+mA
5 6
+EXC.
4-20mA
+EXC.
Process display
Sensor
Input temperature
Pt100
Pt100
1 4 2
Pt1000
Pt1000
1 2
Thermocouple
Thermocouple
-
+
1 2
Potentiometer input
Potentiometer
Potentiometer
Process display
1 2 3 4 5 6 7
Input resistor
Resistor 10kΩ
R 10k
1 2
Resistor 50kΩ
R 50k
1 3
