6 | Operating functions Baumer
18 Operating Manual PA408 | V1
Teach mode (teach-in using measured support points)
The input values are read directly at the input at the time the signal is detected at any point in
the process. Displayed value configuration is done manually using the soft-touch keypad of the
process display. This method is appropriate if the signal values are known at each point but run-
ning the process at the conditions defined by these extreme points is not feasible.
First measured value
The input signal value is automatically adopted.
Display value for the first measured value
The value entered here will be displayed upon the input signal reaching the
first measured value. Ranging from -19999 to 199999
Decimal point dSP1
Positioning decimal point, applies to dSP1 and dSP2.
Second measured value
The input signal value is automatically adopted.
Display value for the second measured value
The value entered here will be displayed upon the input signal reaching the
second measured value. Ranging from -19999 to 199999
Display stabilization filter
Defines the limit frequency of the low-pass filter (Fc) applied to smoothen unwanted display fluc-
tuations.
Programmable from 0 to 9 with the button .
Increasing the filter value reduces the response time of the display. The
value 0 deactivates the filter.
Confirm with .
