Installation

Instruction handbook b maXX 5000

Document No.: 5.09021.16

163

of 328

Connection motor/PE bolt

Connection 1 x 50 mm² Connection 2 x 16 mm²

Cable lug

1 x 50 mm²

Cable lug

2 x 16 mm²

Washer

Nut

Washer

Nut

Spacer

BM537X

Figure 80: Connection motor/PE bolt BM537X
